Gravity Table Separator Machine
Gravity Table Separator Machine
Gravity Table Separator Machine
Gravity Table Separator Machine
Gravity Table Separator Machine
Gravity Table Separator Machine
  • Gravity Table Separator Machine
  • Gravity Table Separator Machine
  • Gravity Table Separator Machine
  • Gravity Table Separator Machine
  • Gravity Table Separator Machine
  • Gravity Table Separator Machine

Gravity Table Separator Machine

    Payment Type: L/C

Basic Info

Model No.:  HELIDA 5XZ

Additional Info

Productivity: 5t, 8t, 10t Per Hour

Place of Origin:  China

Supply Ability: 5t, 8t, 10t Per Hour

Product Description

Gravity Table Separator Machine

Gravity Table Optional Accessories Available:
1. Additional Deck meant for small seeds, like vegetable seeds, grass seeds, flower seeds etc.
2. Vibratory feeder for non-free flowing grains.
3. Also,we could prepare canopy dust system including hood to cover part of the deck, connecting duct, cyclone dust collector with intergral fan as your want.
4. Elevator (to feed specific Gravity Separator).

gravity separator

Salient Features:
Rectangular Deck for greater capacity and accuracy, quickly & easily interchangeable type.
Fans are dynamically balanced with individually adjustable air control for each fan for precise control of air flow.
All the fans are mounted on one common shaft.
Variable oscillation speed of deck in wide range.
Variable inclination of deck sidewise and lengthwise in wide range.
Air Chamber, Sieve Deck assembly and spouts are self cleaning type.
Belt guard provided.
Sieve reciprocating provided by means of eccentric and connecting rods.
Heavy duty and rebust structural frame to absorb the vibrations.
Seed Collecting spouts are fitted with bag holding clamps.
Eccentrics are counter balanced giving smooth oscillation action to the deck.
Built in air filters can be easily removed for easy access to the moving parts.
Screw type arrangement for each fan for controlling the quantity of air.
  • Model NO.: HELIDA 5XZ
  • Transport Package: Nude or Wooden Box Packing
  • Origin: China
  • Trademark: HELIDA
  • Specification: 3700*2300*1800mm
  • HS Code: 8437109000
gravity separator


Parameters:
Model Capacity(T/H) Power
(KW)
Weight
(KG)
Dimension(mm) Area of sieve
(m²)
Remark
5XZ-8 8 11 2200 3700*2300*1800 4.3 blowing type


Hebei HELIDA Grain Selecting Machinery Technology Co., Ltd.use the international advanced equipment testing, testing, quality and stability, superior performance, leading technology.


Salient Features:
The machine is widely used in seeds and agricutural byproducts processing.It's excellent in grain seeds,bean seeds and other seeds selection. It can eliminate inferior grain, moth bitten seeds, rotten seeds, black-powder disease seeds, seed with glumes,sand and stones among the seeds.After sifting,the produce quality,including weight per thousand seed, bud rate, cleanliness and consistency, will be greatly improved.
The machine is practical ,flexible, efficient, user-friendly and mobile. It is reliable, stable, the shock absorbing cover is robust. This machine is technically excellent in its class in China.
The machine is widely used in seeds and agricutural byproducts processing.It's excellent in grain seeds,bean seeds and other seeds selection. It can eliminate inferior grain, moth bitten seeds, rotten seeds, black-powder disease seeds, seed with glumes,sand and stones among the seeds.After sifting,the produce quality,including weight per thousand seed, bud rate, cleanliness and consistency, will be greatly improved. We are the gravity geparator Chinese supplier.

gravity table


Looking for ideal Gravity Table Separator Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Gravity Table Separator are quality guaranteed. We are China Origin Factory of Separator Machine. If you have any question, please feel free to contact us.
